EK1 Mini2+ OBD Flash and Logging Device

  • Sale
  • Regular price $719.99
Shipping calculated at checkout.


IN STOCK



Ships to California and worldwide 🌐

READ-WRITE-LOG-DRIVE

The EK1 Mini2 allows you to get a ECU/TCU tune for your car from us anywhere in the world! It also stores multiple maps and performs logging/DTC functions. Performs basic reset functions as well. We have said for over a decade, a OBD reader should be standard factory tool kit, this is the ultimate user end OBD reader and ECU flash tool, and far more. Logging on EK1 device has similar refresh rate to professional tuner tools.



From the manufacturer

"NKLAB has been working ECU tuning field for 22 years and we’ve released first portable tuning device for end-user in 2009.
All of EK1 solution is based on long technical history for 20 years over and has overwhelming powerful skill.
You can upgrade your engine or gearbox software anywhere anytime"



Please Specify vehicle model in order notes if adding ECU tunes from us.

EK1 Mini2 is a new tool from NKLABS Korea and SXTHNK that allows flashing, logging on nearly all Hyundai's and Kia ECU's and even some TCU's. Read and Write of the ECU without the need for ECU unlocking.



Package contents

1 SD Card adapter to USB and Apple devices

1 Dash mount for EK1 Mini2+ (magnetic mount)

1 OBD power cable

1 SD Card

1 EK1 Mini2+ Device



Custom tuning from N75 Motorsports for ANY Hyundai or Kia ECU supported by this product.

This product is extremely affordable which is exactly why we needed it in our tuning lineup. We already offer EK1 Pro tunes for years now, this device is so affordable, and performance is great, logging is nearly unmatched by any other tool. To make it more affordable for our customers, we offer any staged tune when adding tuning to this product.  This means expensive stage 3 and flame tunes come with the device and a total of 4 variations of tuning available for your vehicle.

When adding a tune you receive 3 variants of that tune, higher octane, pop and bangs, whatever you wish. Even our Showtune which shoots flames. We offer any stage tune for ANY Vehicle supported by the EK1, including our most expensive Anti-Lag/flame or track tuning.

How does it work when adding N75 Motorsports tuning?

1: Receive the device, install it. The blue wire goes to a power source (fuse box) that is 12+ volts and comes on only when Ignition is turn on aka IGN2 (2 presses of the Ignition button, not accessory mode)

2: Read your ECU or ECU ID depending upon vehicle (if unsure please email tunes@n75motorsports.ca) All ECU files will be found in the "Maps" Folder on the SD card.

3: Send your ECU ID/Read file, EKM device serial number (found on the back of the device), VIN number, order number, modifications to your vehicle, and tuning request to tunes@n75motorsports.ca.

4: Make a SXTHNK account, this is used for device updates and bootpatch download (if applicable). (All ECU Write files go into "Maps" Folder on SD card) download the PC update software and update your EK1 Mini2+.

5: We send you your OEM file and base file based on your modifications, via email (tunes@n75motorsports.ca). This is a OTS base map used to gauge your engines performance.

6: Write the Bootpatch if applicable, then write the tuned base file.

7: Using the EK1 Mini2+ log the base file, logging parameters (RPM, Boost or MAP, Relative throttle position, Absolute throttle position, Ignition Timing, AFR, STFT, LTFT and vehicle speed) any additional parameters will help, if your vehicle has wastegate position and target, please add these. (Not all ECUs support this)

8: Send logs (3rd and 4th gear wide open throttle pulls) to tunes@n75motorsports.ca. Logs are found in "Logs" folder on SD card.

9: Receive your updated files to your request via email. All maps go into "Maps" folder on the SD card.

10: Write your desired tuning file and N joy!



EK1 Mini2 Handheld Tuning Device

Mountable device that can be connected to the vehicle when necessary for live data, fault code reading and ECU read/writing. Mount and SD Card reader INCLUDED.

SCREEN AND BODY

The EK1 Mini2 features a full color LCD panel and button style navigation. The interface is easy to navigate and allows users to quickly view data and write tuning files.


SIMPLE CONNECTIVITY

EK1 Mini2 is equipped with an SD Card for easy data transfers. Insert the SD Card into your device to transfer tuning files, datalogs.  PC software is used for updates. Software can be downloaded after making a STXHNK account on SXTHNK's site.
