Intake and Turbo Inlet Upgrade Elantra N Line 1.6T Smartstream / Kona N Line 2021-2023

  • Sale
  • Regular price $429.99 CAD
  • Will be in stock after
Shipping calculated at checkout.


IN STOCK IN BLACK AND RED

Fits Elantra N Line: the bypass hose does not fit the BOV, so a cap is included.

Does not fit 23MY.

Fits: Hyundai Elantra N Line 1.6T Smartstream / Kona N Line 2021-2023. Does not fit 23MY. Forge developed this kit for the Hyundai i20N, and Forge's own compatibility list for it names the Hyundai i20 N 2021- (1.6).

What this is

Forge Motorsport, which describes itself as leading the way in aftermarket products for the Hyundai N division vehicles, developed this Turbo Inlet Adaptor and Intake Tract for the Hyundai i20N. The kit is a full plug and play solution, with a replacement cast turbo inlet adaptor, CNC machined hose couplers, and a silicone high flow inlet hose. Available in Black, Red, and Performance Blue, it is made to increase performance and to transform the look of the engine bay.

Forge turbo inlet kit in Black: silicone inlet hose, cast alloy turbo inlet elbow, CNC machined couplers and clamps

Design

The size of the inlet elbow has increased by over 170%, to maximise the amount of air that can physically flow to the turbo from the inlet tract. The OEM factory alloy cast elbow is small, so Forge made it the key component to target as tuners start to increase the boost levels and performance output of the 1.6l turbocharged engine. The plastic OEM inlet hose also has ribs and steps within the bore, causing turbulence that disturbs and slows the airflow. Without the ribs and steps, the larger Forge silicone turbo inlet hose reduces turbulence over the standard item for better airflow.

Gloved hands holding the Forge cast turbo inlet elbow beside the smaller OEM elbow

OEM ribbed black inlet hose beside the Forge Performance Blue silicone hose and cast elbow

The turbo inlet adaptor is designed in a similar way to a conventional velocity stack: it routes the air directly into the turbocharger and allows more air to be compressed due to its larger capacity. This has a positive effect when accelerating after a long deceleration, or between gear changes, because more air is kept within the intake system.

Why silicone? In development Forge tested an oversized aluminium pipe and found that it started to show signs of heat soak, which hurt the impressive initial power gains: after the third pull on the dyno, the alloy pipe conducted too much heat on this application and the gains started to decrease. Silicone cannot conduct heat as well, so even after six pulls the silicone hose stayed at a steady temperature and did not lose any power.

Close-up of the Forge cast alloy turbo inlet elbow with the Forge logo, joined to the Performance Blue silicone hose

Close-up of the Performance Blue silicone inlet hose with its CNC machined alloy coupler

Features

  • Full plug and play kit: replacement cast turbo inlet adaptor, CNC machined hose couplers and silicone high flow inlet hose
  • Inlet elbow size increased by over 170% over the OEM cast elbow
  • Silicone hose without the ribs and steps of the plastic OEM hose, for less turbulence
  • Silicone stays at a steady temperature: no loss of power after six dyno pulls
  • Works like a velocity stack, keeping more air in the intake system between gear changes
  • The inlet pipe fits directly to the factory airbox
  • Black, Red or Performance Blue
  • Forge dyno result on a Hyundai i20N with the OEM airbox and standard factory filter: nearly 7 BHP and 12NM of torque at peak, and 17NM between 2500 RPM and 3000 rpm
  • Forge Lifetime Warranty

Forge Motorsport blue divider line

Dyno results: Forge's testing was completed using Performance Remap in Gloucester, on their VTEC 4-wheel drive dynamometer, so the data comes from an independent tuner. The test car was a Hyundai i20N. Mated to the OEM airbox and standard factory filter, the kit increased peak power from stock by nearly 7 BHP and 12NM of torque, with significant gains across the entire rev range, so the car picks up quicker and pulls the whole way through to redline. It also gave 17NM between 2500 RPM and 3000 rpm, right as the power comes in, which can really change the feel and power delivery from behind the wheel. After installing a tuning box, or re-calibrating the ECU with stage one or two tunes, Forge expects the performance gains to be a lot higher than these figures.

Dyno screen showing 186 whp during Forge's turbo inlet testing, with the test car on the rollers

Performance Remap dyno sheet for a Hyundai i20N 1.6 MT: stock against the Forge inlet with the stock airbox

Forge turbo inlet kit in Performance Blue: silicone inlet hose, cast alloy elbow, couplers and clamps

Forge turbo inlet kit in Red: silicone inlet hose, cast alloy elbow, couplers and clamps

Forge Performance Blue silicone hose joined to the cast turbo inlet adaptor

Options

  • Color: Performance Blue, Black or Red. In stock in Black and Red.

Installation notes

The kit is a full plug and play solution, and the inlet pipe fits directly to the factory airbox. On the Elantra N Line the bypass hose does not fit the BOV, so a cap is included. It does not fit 23MY. We recommend installation by a qualified technician. Contact us before ordering if you have questions about fitment.

Forge turbo inlet hose in Performance Blue fitted to the OEM airbox in a Hyundai i20N engine bay

Warranty

Forge Motorsport backs this kit with its Lifetime Warranty. Contact us with your order number if you need to make a claim.

FAQ

Does it fit the Elantra N Line?

Yes. On the Elantra N Line the bypass hose does not fit the BOV, so a cap is included. It does not fit 23MY.

What colours are available?

Performance Blue, Black or Red. Black and Red are in stock.

What gains did Forge measure?

On a Hyundai i20N with the OEM airbox and standard factory filter: nearly 7 BHP and 12NM of torque at peak, and 17NM between 2500 RPM and 3000 rpm. Forge expects a lot more with a tuning box or a stage one or two ECU tune.

Do I need a different airbox?

No. The inlet pipe fits directly to the factory airbox.


Customer Reviews

Based on 13 reviews
77%
(10)
8%
(1)
0%
(0)
0%
(0)
15%
(2)
T
Thomas
Fitment confirm

I can also confirm that this fits on 2024 kona nline 1.6l turbo smartstream

X
Xzavyer Adams
Real pain, but definitely noticed a difference

If you have a 2021 US N-Line like me your stock DV hose will not fit AND the actual charge pipe won't fit properly either. You'll need to buy Forge part #FMBH7 to replace it or run a full atmosphere dump BOV. If you pinch the inlet o-ring like I did or manage to lose it trying to install it the OEM part # for that is 282332M900. I also used my stock hardware instead of the hex screws that come with the kit. The oil breather hose was also a huge pain to get off and back on due to the clamp being positioned in a difficult way. You can use needle nose pliers that are hooked to get it better.

To make the charge pipe fit you can either trim a little bit off at the front or run a cone filter with the top of the airbox taken off otherwise you'll have a slight kink in the first bend. I'm running mine with the DV hose disconnected and with that kinked bend and it's completely fine but I won't be running it like that forever.

J
Jorge

Love it!! Perfect fit! Looks awesome.

D
D.B.
Top Notch Qualtiy

Great quailty product. Though install can be slightly tideous working with the tight fitted areas, overall 10/10. Guys here at N75 are always killing it!

A
Abel

No es precisamente para mi auto, el vendedor ofrece que la devuelva, pero no tiene segun el una pieza compatible con mi auto, mala descripción de aplicaciones.

This is installation error.
